Hardware Features
Ports: 1 Gigabit Ethernet Port
Button: WPS Button, Reset Button
Input Power: 100-240V~50/60Hz
Power Consumption: 10W
Dimensions ( W x D x H ): 2.9×1.8×4.9 in. (74.0×46×124.8 mm)
Antenna 2 External Antennas
Wireless Features
Wireless Standards: IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n/x 2.4GHz
Frequency: 2.4GHz and 5GHz
Signal Rate: 574 Mbps at 2.4GHz, 1201 Mbps at 5GHz
Working Modes: Range Extender/Access Point
Reception Sensitivity: 5GHz:
11a 6Mbps: -93dBm,
11a 54Mbps: -75dBm
11ac HT20 MCS0: -92dBm,
11ac HT20 MCS8: -70dBm
11ac HT40 MCS0: -90dBm,
11ac HT40 MCS9: -66dBm
11ac HT80 MCS0: -87dBm,
11ac HT80 MCS9: -62dBm
2.4GHz:
11g 54Mbps: -77dBm,
11n HT20 MCS7: -75dBm
11n HT40 MCS7: -72dBm
Transmit Power CE: 2.4GHz ≤20dBm, 5GHz ≤30dBm
Wireless Functions: Enable/Disable Wireless Radio, Wireless Statistics
Wireless Security: 64/128-bit WEP, WPA/WPA2-PSK encryptions
Mesh Technology One: Mesh
