- – 5× 10/100/1000Mbos Auto-Negotiation RJ45 port, supporting Auto-MDI/MDIX
- – Green Ethernet technology saves power
- – IEEE 802.3X flow control provides reliable data transfer
- – Plastic casing, desktop or wall-mounting design
- – Plug and play, no configuration needed
- – Fanless design ensures quiet operation
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3i/802.3u/ 802.3ab/802.3x
Interface: 5× 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports
Fan Quantity: Fanless
External Power Supply: External Power Adapter (Output: 5VDC/0.6A)
Dimensions ( W x D x H ): 3.5 × 2.8 × 0.9 in. (90 × 72 × 23 mm)
Max Power Consumption: 3.7W
Max Heat Dissipation: 12.617 BTU/h
PERFORMANCE
Switching Capacity: 10 Gbps
Packet Forwarding Rate: 7.4 Mpps
MAC Address Table: 2K
Packet Buffer Memory: 1.5 Mb
Jumbo Frame: 16 KB
