| HARDWARE FEATURES | |
|---|---|
| External Power Supply | 12V/1.5A |
| Interface | 1× 10/100/1000 Mbps RJ45 WAN Port 3× 10/100/1000 Mbps RJ45 LAN Ports |
| Button | Power On/Off Button, Reset Button, Wi-Fi/WPS Button |
| Antenna | Four high-performance external antennas |
| Dimensions ( W x D x H ) | 7.2 × 3.7 × 1.3 in (182.7 × 94.0 × 33.3 mm) |
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | AX3000 5 GHz: Up to 2402 Mbps 2.4 GHz: Up to 574 Mbps |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security | WPA/WPA2/WPA3 encryptions |
| Wireless Standards | IEEE 802.11a/n/ac/ax 5 GHz IEEE 802.11b/g/n/ax 2.4 GHz |
| Transmission Power | CE:<20dBm (2.4GHz); <23dBm (5.15GHz–5.35GHz); <30dBm (5.47GHz–5.725GHz) |
| Multi-SSID | 2× 5 GHz Multi-SSID 2× 2.4 GHz Multi-SSID |
| Wireless Schedule | Support 2.4 GHz and 5 GHz Wireless Schedule |
| Mesh Technology | EasyMesh compatible, and support 802.11k/v/r |
| SOFTWARE FEATURES | |
|---|---|
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP(Multi-EWAN) |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Quality of Service | Hardware QoS, Flow Classification |
| Dynamic DNS | DynDns, NO-IP |
| VPN Pass-Through | IPSec, PPTP, L2TP |
| Access Control | Parental Controls, White List, Black List |
| Firewall Security | DoS, SPI Firewall, IP and MAC Address Binding |
| Management Features | Local management: WebGUI, Aginet app (for end users) Remote management :Aginet ACS, TR-069, TR-098, TR-181, TR-111,TR-143 for service providers Aginet APP for end user (need to log in wtih TP-Link ID and bind your device to it) Cloud management: TP-Link Aginet Unified Cloud (TAUC) |
| Advanced Features | TX Beamforming, MU-MIMO, DL/UL OFDMA, Airtime Fairness |
| Protocols | IPv4, IPv6 |
| Operating Modes | Router, Access Point |
| VPN Server | PPTP, OpenVPN, IPSec |
