- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*3, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Two 10GE SFP+ Ports: 1× WAN and 1× WAN/LAN 10GE SFP+ ports provide high-bandwidth aggregation connectivity.
- Up to 10 WAN Ports: Fiber and RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband.
- Highly Secure VPN: Enterprise-standard SSL/ IPSec / PPTP / L2TP VPN & OpenVPN / L2TP over IPSec VPN are ideal for use across multiple branches and for WFH.
- Abundant Security Features: Powerful Firewall, DoS defense, IP/MAC/URL filtering, and IP-MAC Binding, and One-Click ALG Activation provide world-class security.
SECURITY
Access Control: Source/Destination IP Based Access Control
Filtering:
– WEB Group Filtering
– 5 URL Filtering
– Web Security5
ARP Inspection:
– Sending GARP Packets5 ARP Scanning5
– IP-MAC Binding*5
Attack Defense:
– TCP/UDP/ICMP Flood Defense
– Block TCP Scan (Stealth FIN/Xmas/Null)
– Block Ping from WAN
HARDWARE FEATURES
Standards and Protocols:
– IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
– TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
Interface:
– 2× 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)
– 1× 1GE SFP WAN/LAN Ports
– 8× 1GE RJ45 WAN/LAN Ports
– 1× RJ45 Console Ports
– 2× USB Ports (Connecting 4G/3G Modem as WAN Backup)
Network Media :
– 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)
EIA/TIA-568 100Ω STP (Max 100 m)
– 100BASE-TX: UTP category 5, 5e cable (Max 100 m)
EIA/TIA-568 100Ω STP (Max 100 m)
– 1000BASE-T: UTP category 5e, 6 cable (Max 100 m)
Fan Quantity: 2
Button: Reset Button
Power Supply: Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz)
PoE Budget: –
Flash: 4MB SPI NOR + 256 MB NAND
DRAM: 4 GB DDR4
LED: PWR, SYS, WAN, LAN, USB, FAN
Dimensions ( W x D x H ): 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)
Protection: 4 kV surge protection
Enclosure: Steel
Mounting: Rack Mountable
Max Power Consumption:
– 26.36 W (with USB 3.0 connected)
– 19.12 W (without USB 3.0 connected)
