Features
12-Stream 22 Gbps Tri-Band WiFi: 11520 Mbps (6 GHz) + 8640 Mbps (5 GHz) + 1376 Mbps (2.4 GHz).
Unprecedented 10 Gbps Network: 1x 10 Gbps Ethernet/Fiber Combo WAN/LAN port + 1x 10 Gbps WAN/LAN port + 2x 2.5 Gbps ports ensure max flexibility and boosted throughput.
Wireless and Wired Combined Backhaul: Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency.
Multi-Link Operation (MLO): Simultaneously send and receive data across different bands and channels to increase throughput, reduce latency, and improve reliability.
320 MHz Channels: Double the bandwidth and enables many more simultaneous transmissions at the fastest possible speeds.
Works on the 6 GHz Band: Minimizes congestion with greenfield spectrum, delivering robust high-speed connections.
TP-Link HomeShield: Provides comprehensive network protection, robust parental controls, and real-time IoT security.*
Universal Compatibility: Backward compatible with all WiFi generations.
Technical Specification
Ports
1x 10 Gbps
1x 10 Gbps SFP+/RJ45 Combo
2x 2.5 Gbps
1x USB 3.0
*Per Deco Unit
WiFi Standards – Wi-Fi 7
IEEE 802.11be/ax 6 GHz
IEEE 802.11be/ax/ac/n/a 5 GHz
IEEE 802.11be/ax/n/b/g 2.4 GHz
WiFi Speeds – BE22000
6 GHz: 11520 Mbps (802.11be)
5 GHz: 8640 Mbps (802.11be)
2.4 GHz: 1376 Mbps (802.11be)
WiFi Range Broader – Broader Whole Home Coverage
TP-Link Mesh Technology
AI-Driven Mesh
8x High-Gain Antennas (Internal)
Tri-Band
WiFi Capacity – Very High
Tri-Band
4×4 MU-MIMO
OFDMA
12 Streams
Working Modes
Network Security
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
Advanced Functions
Multi-Link Operation (MLO)
320 MHz Channel
4K-QAM
Multi-RUs
Works with Alexa and Google Assistant
