- High Wi-Fi Speed – AC600 (200 Mpbs on 2.4GHz band and 433 Mbps on 5GHz band) wireless speed with the next generation Wi-Fi – 802.11ac
- Dual Band Wireless –Selectable Dual Band connections for lag-free HD video streaming and gaming
- Mini design – A tiny way to get speedy next generation Wi-Fi connections
- Operating System – Windows 10/8.1/8/7/XP, Mac OS X
- Advanced Security –Supports 64/128-bit WEP, WPA/WPA2, and WPA-PSK/WPA2-PSK encryption standards
HARDWARE FEATURES
Interface: USB 2.0
LED: Status
Dimensions ( W x D x H ): 1.6×0.7×0.3 in. (41×19.5×8.7mm)
Antenna Type: Omni Directional
WIRELESS FEATURES
Wireless Standards:
IEEE 802.11ac, IEEE 802.11a,
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency:
5GHz
2.4GHz
Signal Rate:
5GHz
11ac: Up to 433Mbps(dynamic)
11n: Up to 150Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz
11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity:
5GHz：
11a 6Mbps: -94dBm
11a 54Mbps: -78dBm
11n HT20 MCS0: -94dBm
11n HT20 MCS7: -77dBm
11n HT40 MCS0: -92dBm
11n HT40 MCS7: -74dBm
11ac VHT80 MCS0: -89dBm
11ac VHT80 MCS9: -64dBm
2.4GHz:
11b 1Mbps: -99dBm
11b 11Mbps: -91dBm
11g 6Mbps: -94dBm
11g 54Mbps: -77dBm
11n HT20 MCS0: -95dBm
11n HT20 MCS7: -76dBm
11n HT40 MCS0: -92dBm
11n HT40 MCS7: -73dBm
Transmit Power : <20dBm (EIRP)
Wireless Modes: Ad-Hoc / Infrastructure mode
Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x
Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
