excerpt: Dual-Core CPU, 1x Gbit WAN, 4 x Gbit LAN, 802.11ax, 2.4 + 5 GHz, 574 + 1201 Mbps, 260.2 x 135.0 x 38.6 mm
wpid: 480911
product_brand:
  - TP-Link
product_type:
  - simple
product_visibility:
  - featured
product_cat:
  - Networking
  - Routers
featured_image: "https://tech.co.za/wp-content/uploads/2024/08/ARCHER-AX23a.jpg"
---

- Super-Fast 1.8 Gbps Wi-Fi – Enjoy smooth 4K streaming and downloading with super-fast Wi-Fi speeds of 1.8 Gbps.†
- Connect More Devices – Communicates with more devices using OFDMA while simultaneously reducing lag.‡
- Broader Coverage – Improved algorithm, beamforming, and high-performance antennas enhance the Wi-Fi coverage performance.§
- Next-Gen Platform – The Next-Gen High-Efficiency Chipset provides fast and stable Wi-Fi while saving power consumption.△
- Parental Controls – Enjoy the most versatile yet free parental controls features among all routers, including URL blocking, profile management, pausing, and more.
- Works with Most ISPs – Compatible with most ISPs with extra L2TP/PPTP support. IPTV support works with your existing TV over the Internet contract.
- OneMesh – Use with OneMesh extenders to get whole-home coverage and enjoy smooth roaming between signals.
- Easy Setup – Set up your router in minutes with the powerful TP-Link Tether App.
- Backward Compatible – Supports all previous 802.11 standards Wi-Fi devices.

**SECURITY**
Network Security:
– SPI Firewall
– Access Control
– IP & MAC Binding
– Application Layer Gateway

Guest Network:
– 1× 5 GHz Guest Network
– 1× 2.4 GHz Guest Network

VPN Server:
– OpenVPN
– PPTP

WiFi Encryption:
– WPA
– WPA2
– WPA3
– WPA/WPA2-Enterprise (802.1x)

**WIRELESS**
Standards: Wi-Fi 6
– IEEE 802.11ax/ac/n/a 5 GHz
– IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds: AX1800
– 5 GHz: 1201 Mbps (802.11ax)
– 2.4 GHz: 574 Mbps (802.11ax)

WiFi Range: 2-3 Bedroom Houses
– 4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
– Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range

WiFi Capacity: High
– Dual-Band
Allocate devices to different bands for optimal performance
– OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
– Airtime Fairness
Improves network efficiency by limiting excessive occupation
– 4 Streams
Connect your devices to more bandwidth

Working Modes: Router Mode, Access Point Mode

**OTHER**
System Requirements:
– Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
– Cable or DSL Modem (if needed)
– Subscription with an internet service provider (for internet access)

Certifications: FCC, CE, RoHS

Environment:
– Operating Temperature: 0℃~40℃ (32℉ ~104℉)
– Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
– Operating Humidity: 10%~90% non-condensing
– Storage Humidity: 5%~90% non-condensing

**PHYSICAL**
Dimensions (W×D×H): 10.2 × 5.3 ×1.5 in (260.2 × 135.0 × 38.6 mm)

Package Contents:
– Wi-Fi Router Archer AX23
– Power Adapter
– RJ45 Ethernet Cable
– Quick Installation Guide
