Wireless
Working Modes: Range Extender/Access Point
Hardware Features
Standards and Protocols: IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Plug Type: EU, UK, US, AU, KR, JP
Interface: 1 x 10/100/1000M Ethernet Port (RJ45)
Ports: 1 Gigabit Ethernet Port
Button: WPS Button, Reset Button, LED Button, Power Button
Input Power: 100-240V~50/60Hz
Power Consumption: 10W（max power consumption）
Dimensions ( W x D x H ): 6.4 x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm)
Antenna: 3 External Antennas
Wireless Features
Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency: 2.4GHz and 5GHz
Signal Rate: 600Mpbs at 2.4GHz, 1300Mbps at 5GHz
Working Modes: Range Extender/Access Point
Reception Sensitivity
5GHz：
11a 6Mbps:-93dBm
11a 54Mbps: -76dBm
11ac HT20 mcs8: -68dBm
11ac HT40 mcs9: -64dBm
11ac HT80 mcs9: -61dBm
2.4GHz:
11g 54Mbps: -77dBm
11n HT20 mcs7: -73dBm
11n HT40 mcs7: -70dBm
Wireless Modes: Range Extender/Access Point
Wireless Functions
Enable/Disable Wireless Radio
DFS (the latest firmware and hardware version is required)
Access Control
LED Control
Power Schedule
Wi-Fi Coverage
Wireless Security: 64/128-bit WEP, WPA-PSK / WPA2-PSK
Transmission Power: 2.4G<20dBm, 5G<23dBm
