Hardware Features
Ports: 1 x 10/100Mbps Ethernet Port (RJ45)
Button: WPS Button, Reset Button
Input Power: 100-240V~50/60Hz
Power Consumption: 9.5W（max power consumption）
Dimensions ( W x D x H ): 3.5×1.4×4.9 in. (89×35.0×124.1 mm)
Antenna: 2 External Antennas
Wireless Features
Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency: 2.4GHz and 5GHz
Signal Rate: 300Mbps at 2.4GHz, 867Mbps at 5GHz
Working Modes: Range Extender/Access Point
Reception Sensitivity:
5 GHz:
11a 6Mbps: -94dBm
11a 54Mbps: -77dBm
11ac HT20 MCS0: -94dBm
11ac HT20 MCS8: -71dBm
11ac HT40 MCS0: -92dBm
11ac HT40 MCS9: -66dBm
11ac HT80 MCS0: -87dBm
11ac HT80 MCS9: -62dBm
2.4 GHz:
11g 54Mbps: -78dBm
11n HT20 MCS7: -76dBm
11n HT40 MCS7: -74dBm
Wireless Functions
Enable/Disable Wireless Radio
DFS (the latest firmware and hardware version is required)
Access Control
LED Control
Power Schedule
Wi-Fi Coverage
Wireless Security: 64/128-bit WEP, WPA/WPA2-PSK/WPA2-PSK2 encryptions
Transmission Power: 2.4 GHz ≤20dBm, 5 GHz ≤30dBm
Wireless Functions
Enable/Disable Wireless Radio
DFS (the latest firmware and hardware version is required)
Access Control
LED Control
Power Schedule
Wi-Fi Coverage
Wireless Security: 64/128-bit WEP, WPA/WPA2-PSK/WPA2-PSK2 encryptions
Transmission Power: 2.4 GHz ≤20dBm, 5 GHz ≤30dBm
