- 9× 10/100 Mbps RJ45 ports
- 8× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 65 W for 8 PoE ports*
- Up to 250 m data and power transmitting range under Extend Mode**
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
- Isolation Mode allows one-click client traffic separation for higher security and performance
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices.
- Plug and play with no configuration required
HARDWARE FEATURES
Interface:
– 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ ports)
– AUTO Negotiation
– AUTO MDI/MDIX
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: Yes
External Power Supply: External Power Adapter (Output: 53.5VDC / 1.31A)
Packet Forwarding Rate: 1.3392 Mpps
– PoE Ports (RJ45):
– Standard: 802.3 af/at compliant
– PoE Ports: Ports 1–8
– Power Supply: 65 W
Mac Address Table: 2K
Jumbo Frame: 2 KB
Switching Capacity: 1.8 Gbps
Dimensions ( W x D x H ): 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Max Power Consumption:
– 3.28 W (220/50 Hz. no PD connected)
– 74.33 W (220/50 Hz. with 65 W PD connected)
Max Heat Dissipation:
– 11.18 BTU/h (no PD connected)
– 253.47 BTU/h (with 65 W PD connected)
