Hardware Features
Interface
8× 10/100/1000Mbps RJ45 Ports (Ports 1–8 supports 802.3af/at PoE+)
AUTO Negotiation
AUTO MDI/MDIX
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Installation
Desktop
Wall Mounting
Power Supply: External Power Adapter (Output: 53.5 VDC / 1.31 A)
PoE Ports (RJ45)
Standard: 802.3 af/at compliant
PoE Ports: Ports 1–8, up to 30 W PoE output per port
PoE Budget: 62 W
Dimensions ( W x D x H ): 6.2×3.9×1.0 in (158×99×25 mm)
Max Power Consumption
5.53 W (220 V/50 Hz. no PD connected)
71.61 W (220 V/50 Hz. with 62 W PD connected)
Max Heat Dissipation
18.81 BTU/h (220 V/50 Hz. no PD connected)
243.47 BTU/h (220 V/50 Hz. with 62 W PD connected)
Performance
Switching Capacity: 16 Gbps
Packet Forwarding Rate: 11.9 Mpps
MAC Address Table: 4K
Jumbo Frame: 16 KB
