- 6× 10/100 Mbps RJ45 ports
- 4× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- Up to 250m data and power transmitting range under Extend Mode**
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 67 W for all PoE ports*
- Plug and play with no configuration required
HARDWARE FEATURES
Interface:
– 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+)
– AUTO Negotiation
– AUTO MDI/MDIX
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: Yes
External Power Supply: External Power Adapter (Output: 53.5 V DC / 1.31 A)
Packet Forwarding Rate: 0.8928 Mpps
PoE Ports (RJ45):
– Standard: 802.3 af/at compliant
– PoE Ports: Ports 1–4
– Power Supply: 67 W
Mac Address Table: 2K
Jumbo Frame: 2 KB
Switching Capacity: 1.2 Gbps
Dimensions ( W x D x H ): 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm)
Max Power Consumption:
– 2.52 W (220 V / 50 Hz, no PD connected)
– 75.4 W (220 V / 50 Hz, with 67 W PD connected)
Max Heat Dissipation:
– 8.59 BTU/h(no PD connected)
– 257.11 BTU/h(with 67 W PD connected)
