Features
Static route: Yes
DHCP server: Yes
DHCP relay: Yes
IGMP snooping: Yes
Multicast Listener Discovery (MLD) snooping: Yes
Quality of Service (QoS) support: Yes
GPON split ratio (max): 1:128
Maximum operating distance (GPON): 20000 m
Access Control List (ACL): Yes

Ports & interfaces
Upstream ports: Gigabit Ethernet
Ethernet LAN (RJ-45) ports: 2
GPON ports quantity: 4

Ports & interfaces
SFP/SFP+ slots quantity: 1

Power
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
DC voltage range: 38.4 – 72 V
Power consumption (max): 58 W

Weight & dimensions
Width440 mm
Depth180 mm
Height44 mm
