With 433Mbps wireless speeds over the crystal clear 5GHz band and 300Mbps over the 2.4GHz band, Archer C20 offers you the flexibility of two dedicated networks and ensures amazing wireless performance. Simple tasks such as sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band – all at the same time.
Simultaneous 300 Mbps at 2.4 GHz and 433 Mbps at 5 GHz for 733 Mbps total available bandwidth
Three external antennas provide stable omnidirectional signal and superior wireless coverage
Supports three modes：Router，Range Extender and Access Point Modes
IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize HD streaming
Parental Controls manage when and how connected devices can access the internet
Guest Network provides separate access for guests while securing the host network
WIRELESS
Standards: Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds: AC750
5 GHz: 433 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)
WiFi Range: 2 Bedroom Houses3× Fixed Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity: MediumDual-Band
Allocate devices to different bands for optimal performance
Working Modes: Router Mode
Access Point Mode
Range Extender Mode
HARDWARE
Processor: Single-Core CPU
Ethernet Ports: 1× 10/100 Mbps WAN Port
4× 10/100 Mbps LAN Ports
Buttons: WPS/Wi-Fi Button
Power On/Off Button
Reset Button
Power: 9 V ⎓ 0.6 A
SECURITY
WiFi Encryption: WEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
Network Security: SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network: 1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
SOFTWARE
Protocols: IPv4
IPv6
Parental Controls: URL Filtering
Time Controls
WAN Types: Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service: QoS by Device
NAT Forwarding: Virtual Server
Port Forwarding
Port Triggering
DMZ
UPnP
IPTV: IGMP Proxy
IGMP Snooping
DHCP: Address Reservation
DHCP Client List
Server
DDNS: NO-IP
Comex
DynDNS
Management: Tether App
Webpage
