- – 2.36” LCD screen capable of displaying 24-bit color
- – Customize display with intuitive NZXT CAM controls
- – NZXT RGB Connector for NZXT RGB accessories
- – Two 140mm Aer RGB 2 radiator fans with fluid dynamic bearing
- – Fine nylon mesh sleeves strengthens rubber tubing to protect from leaks
- – 6-year warranty
- – LGA 1700 Bracket Request Form
Water Block
- Dimensions:Diameter: 79mm / H: 52mm
- Material (Block):Copper
- Material (Housing):Plastic
Pump
- Motor Speed:800 – 2,800 ± 300 RPM
- Power:12V DC, 0.3A
Radiator
- Dimensions:143 x 315 x 30mm
- Material:Aluminum
Tube
- Length:400mm
- Material:Ultra-low Evaporation Rubber with Nylon Braided Sleeve
Cap
- Material:Aluminum, Plastic
- Fan Control:Yes
- NZXT RGB Channel Connector:1
- Rotation Orientation:Software adjustable Default, +90, +180, and -90 Degrees
LCD Display Panel
- Active Area:2.36” (60mm) Diameter
- Color:24-bit True Color LCD
- Resolution:320 x 320px
- Brightness:650 cd/m²
Fan Specs
- Model:Aer RGB 2 140mm
- Quantity:2
- Dimension:140 x 140 x 26mm
- Speed:500 – 1,500 ± 300RPM
- Airflow:30.39 – 91.19 CFM
- Air Pressure:0.17 – 1.52 mm-H₂O
- Noise:22 – 33 dBA
- Bearing:Fluid Dynamic Bearing
- Power Consumption:12V DC, 0.32A, 3.8W
- Fan Connector:4-pin PWM
- Life:60,000 hours / 6 Years
Compatible Socket & CPU
- Intel:Socket LGA 1700, 1200, 115X
- AMD:AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included)
