Key Specs
-
Motherboard Support: Mini-ITX, MicroATX, ATX
-
Enclosure Type: Compact Mid-Tower
-
Case Material: SGCC Steel, Tempered Glass
Dimensions
-
Height: 460 mm / 18.11 inches
-
Width: 210 mm / 8.26 inches
-
Depth: 428 mm / 16.85 inches
-
Weight: 6.6 kg / 14.5 lb
Compatibility & Clearance
-
Max CPU Cooler Clearance: 165 mm
-
Max GPU Clearance: 360 mm
-
Front Fan & Radiator Clearance: 60 mm
-
Cable Management: 19 – 23 mm
Front I/O Ports
-
USB 3.2 Gen 1 Type-A: 1
-
USB 3.2 Gen 2 Type-C: 1
-
Headset Audio Jack: 1
Expansion Slots
-
Standard: 7
-
Vertical: –
Drive Bays
-
2.5″: 2 + 1
-
3.5″: 2 + 1
Fan Support
-
Front: 2 x 120mm / 2 x 140mm
-
Top: 1 x 120mm / 1 x 140mm
-
Rear: 1 x 120mm
-
Filters: All air intake
Included Fans
-
Front: 1 x Aer F 120mm (Case Version)
-
Top: –
-
Rear: 1 x Aer F 120mm (Case Version)
Radiator Support
-
Front: 280mm
-
Rear: 120mm
Fan Specs
-
Model: Aer F 120mm (Case Version)
-
Speed: 1,200 ± 200RPM
-
Airflow: 50.42 CFM
-
Noise: 28 dBA
-
Bearing: Rifle Bearing
-
Fan Connector: 3-pin
