Features
• Pure sine wave output
• 2000 cycles lifePO4 battery
• Mains supply mode, Battery mode
• 5V DC USB 2.0 ports
• 12V DC output ports
• MPPT solar charge controller
• Over charge protection as well as over discharge protection
• Intelligent exhaust fan
Inverter Specifications
Rated Power: 1 000VA / 1 000W
SOLAR CHARGER
Solar Charger Type: MPPT
Maximum PV Array Power: 840W
Number of MPPTs: 1
MPPT Range @ Operating Voltage: 35 – 100V DC
Maximum Solar Current Charger: 30A (Max)
Floating Charge Voltage: 28.4V DC
INPUT
Voltage range: 140 – 275V
Mains charging current: 10A
Frequency Range: 45-65Hz
OUTPUT
Voltage: 230V AC
Frequency: 50/60Hz
Output wave form: Pure Sine Wave
BATTERY
Battery Voltage: 25.6V DC
Battery capacity: 1X 50Ah
Battery cycle life: 2 000 Cycles @ DOD 80%
DC OUTPUT
Low Voltage recovery: 26.8V DC
Low Voltage Protection: 22.4V DC
5V DC USB Output: 2 Pcs 5V DC, USB 2.0, Max 2A
12V DC Output Ports: 2 Pcs Max 2A
Warning:
Charging and discharging a battery multiple times a day will significantly deteriorate its performance. Please note the limitations of each battery technology:
- Lead-acid batteries can only be discharged up to 50% before irreversible damage occurs.
- Gel lead-batteries can often be discharged up to 70% before irreversible damage occurs.
- Lithium batteries can be fully discharged if they are protected by a Battery Management System.
Due to the above limitations, loss of battery capacity is not covered under warranty.
