Screen
- Size: 10.1” diagonal
- IPS (In-Plane Switching)
- LCD Panel with LED Backlighting
- Resolution: 1280 x 800 resolution
- Touch: Capacitive, 10 points multi-touch
- Brightness: 400 nits
- Contrast: 1000:1
- Anti Fingerprint: Oleophobic coating
- Viewing angle: 85 degrees (U/D/L/R)
- Position angle: 0 degrees (flat on mounting surface)
General Specifications
- Integrated accelerometer
- Integrated ambient light sensor
- 100 mm x 100 mm VESA FDMI
- Cable exits: horizontal / vertical / center
COMPATIBILITY AND CERTIFICATIONS
- Logitech Tap Scheduler integrates with leading room scheduling solutions as a
- Logitech Room Booking
- Microsoft Teams Panel
- Zoom Rooms Scheduling Display
- Robin-Powered scheduling panel
- Appspace
- RICOH Spaces
- Envoy Rooms
- Korbyt Booking
- Comeen
- See www.logitech.com/support/tapscheduler-compatibility for the latest certification and compatibility information.
- Logitech CollabOS platform
- Logitech Sync Remote Management
Power and Cables
- Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3 device.
- *Requires PoE enabled network or PoE Injector and ethernet cable (Not included)
PORTS AND INTERFACES
- Ethernet: 10/100 Mbps
- WiFi: 802.11a/b/g/n/ac
- Bluetooth 5.0 (inactive, reserved for future use)
