title: Honeywell 1990IXR-3USB Handheld Scanner
date: 2025-05-21T07:14:09Z
modified: 2026-05-20T12:06:06Z
permalink: "https://tech.co.za/product/honeywell-1990ixr-3usb/"
type: product
status: publish
excerpt: "Built to survive harsh treatment including 3 m drops, 7,000 1 m tumbles, operating temperatures from -30°C to 50°C to and IP67 sealing, Granit XP reduces service costs and increases device uptime.\\nGranit provides extreme performance scanning, even on damaged and low-quality barcodes. High-quality barcodes scan and transmit faster than ever.\\nThe XR model is ideally suited to normal, near-field scanning operations on 1D and 2D barcodes, plus expanded range scanning of UPC to 1.5 m  and 100 mil codes to 10 m.\\nThe Honeywell Scanner Management Utility (SMU) creates a holistic solution that automates how you deploy and update the scanners in your environment."
wpid: 539173
product_brand:
  - OEM
product_type:
  - simple
product_visibility:
  - featured
product_cat:
  - Barcode Scanners
  - POS
  - POS Accessories
featured_image: "https://tech.co.za/wp-content/uploads/2025/05/1990IXR-3USB-Rc.jpg"
---

| Overall Dimensions | 192 mm x 76 mm x 100 mm 7.6 in x 3.0 in x 3.9 in |
| --- | --- |
| Scanning Specifications | Skew: 65° Scanning Range: Flex Range (XR) Scan Pattern: Area Imager (1280 x 800 pixel array) Print Contrast: 20% minimum reflectance difference Motion Tolerance: -Up to 177 in/s -Up to 4500 mm/s Decode Capability: 1D/2D |
| Brightness | – 0 to 100,000 lux – 9,290 foot-candles |
| Bluetooth | No |
| Hardware | Host System Interface: -Keyboard Wedge -RS-232 TTL -USB |
| Electrical | 0.5 W |
| Environmental | Storage Temperature Range: -40°C to 70°C -40°F to 158°F Operating Humidity: Up to 95% relative humidity, non-condensing |
| Standards & Approvals | Tumble Specifications: 7,000 1 m (3.3 ft) tumbles Drop Specifications: -2 m (6.5 ft): 50 drops from -30°C to 50°C (-22°F to 122°F), uncontrolled RH -2.4 m (8 ft): 20 drops at 25°C (77°F), 55% RH -3 m (10 ft): MIL-STD-810G, 25°C (77°F), 55% RH |
| Others | Battery Type: Li-ion Battery Operating Power: 2.35 W (470 mA @ 5 VDC) Input Voltage: 4.0 VDC to 5.5 VDC Operating Temperature: -22°F to 122°F -30°C to 50°C Brand: Honeywell Scan Distance: Mid Range (0-5m) Power Connector Type: Corded IP Rating: IP65 / IP67 Connectivity: Corded Charging: Contact Charging |
