Detection Performance
- Detection Method : Passive infrared, microwave
- Sensor Model : SFG323-711
- Detection Range : 15 m
- Detection Angle : 90° @180° adjustable
- Detection Zones : 92
- Detectable Speed : 0.3 to 2m/s
- Sensitivity : Auto, low
- White Light Filter : 10000lux
- Pet Immunity : 40 kg
- Microwave Frequency : 24 GHz(24.15 to24.25 GHz)
- Digital Temperature Compensation : Support
- Anti-masking : Support
- Adaptable Coverage
- Support,
- Pattern mask included
Feature
- Digital Processing : Tri-Signal logic
- Sealed Optics : Support
- Tamper Protection : Front, rear
- Environment Temperature Indicator : Support
- Signal Strength Indicator : Support
- Anti-Sway Analytics : Support
Interface
- Power Switch : Power up enrolling
- LED Indicator
- Green(Top PIR), Red(Microwave), Orange(Bottom PIR), Green+Orange(Mask),
- Blue(Alarm)
Transmission
- Transmission Technology : Tri-X wireless
- Transmission Method : Two-Way RF wireless
- Transmission Frequency : 868 MHz
- Transmission Security : AES-128 encryption
- Transmission Range(Free Space) : 1.6 km
- Frequency Hopping : Support
- Enrolling Method : Power up, remote ID, QR code
Electrical Characteristics
- Standard Battery Life : Up to 5 years (standby time)(The battery working time can be significantly reduced at low temperatures)
- Power Supply : Battery powered
- Battery Type : CR123A × 5
- Typical Voltage : 3V
General
- Operation Temperature : -25°C to 60°C (-13°F to 140°F)
- Storage Temperature : -25°C to 60°C (-13°F to 140°F)
- Operation Humidity : 10% to 90%
- IP Rate : IP65
- Dimension(WxHxD) : 75 mm × 202 mm × 73 mm
- Weight : 600 g
- Mounting Height : 0.8 m to 1.2 m
- Mounting Method : Wall
- Application Scenario : Outdoor
