Thermal Module
Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Resolution: 256 × 192
Pixel Pitch: 12 μm
Spectral Range: 8 μm to 14 μm
NETD: < 40 mK (25°C, F1.0)
Focal Length: 9.7 mm
IFOV: 1.24 mrad
Field of View: 18.0° × 13.5° (H × V)
Min. Focusing Distance: 1.5 m
Aperture: F1.0
Digital Zoom: ×2, ×4
Optical Module
Image Sensor: 1/2.7″ Progressive Scan CMOS
Resolution: 2688 × 1520
Min. Illumination: 0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
Shutter Speed: 1 s to 1/100,000 s
Focal Length: 8.0 mm
Field of View: 39.4° × 22.1° (H × V)
Aperture (Range); F1.6
WDR: 120 dB
Image Effect
Target Coloration: Yes. Supported in white hot and black hot mode.
Illuminator
IR Distance: Up to 30 m
IR Intensity and Angle: Automatically adjusted
Audible and Visual Alarm
White Light Range: Up to 30 m
Visual Alarm: Yes. White light alarm with adjustable flashing frequencies
Audio alarm
Yes, for two types of audible alarm (VCA and Temperature Exception)
2 preset voice alerts (one for each)
6 importable user-defined voice alerts (6 options shared in the two types)
Network
Protocols: IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP,TLS
Network Storage; MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API: ISAPI, HIKVISION SDK,ISUP, and third-party management platform, Open Network Video Interface,ONVIF (Profile S, Profile G)
Simultaneous Live View: Up to 20 channels
User/Host level: Up to 32 users, 3 levels: Administrator, Operator, User
Security: User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client: iVMS-4200, Hik-Connect
Web Browser
Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0 +, Firefox 52.0 +
