Hardware features
- Serial port : 1
- Power switch : 1
- Alarm input : 1 Alarm, 1 Tamper
- Alarm output : 1 PGM, AM/Output
- 3.3v Output : 1, up to 10mA
Electrical characteristics
- Power supply : 3 CR123
- Operation humidity : 10%~90%
- Operation temperature : –10°C ~ 55°C
- Power consumption
- Quiescent current: 40.29 uA
- Max current: 47.85mA
- Voltage: 3 VDC
- Battery life span : More than 5 years (report alarm 50 times per day)
Wireless transmission
- RF frequency : 868MHz
- RF method : Two-way communication
- RF modulation : 2GFSK
- RF distance : 1700m
Display
- Indicator : 3: Alarm/Tamper(Red), Fault(Amber), Signal Strength
(Green/Red)
General
- Installation method : Put inside Wireless Ready Detector
- Dimension(WxHxD) : 102*41*20mm
- Weight : 35g(Without Battery), 90g(With Battery)
