Video and Audio
- IP Video Input 8-chUp to 6 MP resolution
- Incoming Bandwidth 60 Mbps
- Outgoing Bandwidth 60 Mbps
- HDMI Output 1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output 1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Video Output Mode HDMI/VGA simultaneous output
Decoding
- Decoding Format H.265+/H.265/ H.264+/H.264
- Recording Resolution 6 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Synchronous playback 4-ch
- Decoding Capability 4-ch@1080p (30 fps) or 2-ch@4 MP (30 fps) or 1-ch@6 MP (30 fps)
- Stream Type Video, Video & Audio
Network
- Remote Connection 16
- Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™
- Network Interface 1, RJ-45 10/100Mbps self-adaptive Ethernet interface
Auxiliary Interface
- SATA 1 SATA interface
- Capacity Up to 6TB capacity for each disk
- Alarm In/Out N/A
- USB Interface Rear panel: 2 × USB 2.0
General
- Power Supply 12 VDC, 1.5 A
- Consumption ≤ 10 W
- Working Temperature -10 to +55º C (+14 to +131º F)
- Working Humidity 10% to 90%
- Dimension (W × D × H) 200 × 200 × 48 mm (7.9″ × 8.1″ × 1.9″)
- Weight ≤ 1 kg (2.2 lb)
Certification
- CE EN50130-4, EN 61000-3-2,EN 61000-3-3
