Camera
- Image Sensor 1/2.8″ Progressive Scan CMOS
- Max. Resolution 2560 × 1440
- Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Speed 1 s to 1/30,000 s
- Day & Night IR cut filter
- Zoom 25x optional, 16x digital
- Slow Shutter Yes
Lens
- Focal Length 4.8 mm to 120 mm
- FOV Horizontal field of view: 55° to 2.4° (wide-tele),Vertical field of view: 33° to 1.4° (wide-tele),Diagonal field of view: 61.5° to 2.8° (wide-tele)
- Focus Auto, semi-auto, manual
- Aperture Max. F1.6
- Zoom Speed Approx. 3.6 s
Illuminator
- Supplement Light Type IR
- Supplement Light Range IR Distance: up to 150 m
PTZ
- Movement Range (Pan) 360°
- Movement Range (Tilt) -15° to 90° (auto flip)
- Pan Speed Pan speed: configurable from 0.1° to 120°/s; preset speed: 120°/s
- Tilt Speed Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
- Proportional Pan Yes
- Presets 300
- Preset Freezing Yes
- Patrol Scan 8 patrols, up to 32 presets for each patrol
- Pattern Scan 4 pattern scans
- Park Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
- 3D Positioning Yes
- PTZ Status Display Yes
- Scheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
- Power-off Memory Yes
Video
- Main Stream 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
- Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video Compression Main stream: H.265+/H.265/H.264+/H.264Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
- Video Bit Rate 32 Kbps to 16 Mbps
- H.264 Type Baseline profile/Main profile/High profile
- H.265 Type Main profile
- Scalable Video Coding (SVC) H.264 and H.265 encoding
- Region of Interest (ROI) 8 fixed regions for each stream
Audio
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)
- Audio Sampling Rate 8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering Yes
Network
- Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PP PoE, Bonjour
- Simultaneous Live View Up to 20 channels
- API Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
- User/Host Up to 32 users; 3 user levels: administrator, operator, and user
- Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)
- Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- Client iVMS-4200, Hik Central Pro, Hik-Connect
- Web Browser IE11, Chrome57+, Firefox52+, Safari11+
- Image Parameters Switch Yes
- Image Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Day/Night Switch Day, Night, Auto, Schedule
- Wide Dynamic Range (WDR) 120 dB
- SNR ＞52 dB
- Defog Digital Defog
- Image Stabilization No
- Image Enhancement BLC, HLC, 3D DNR
- Privacy Mask 24 programmable polygon privacy masks, mask color or mosaic configurable
- Regional Focus Yes
- Regional Exposure Yes
Interface
- Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
- On-board Storage Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;1 output (line out), line level, output impedance: 600 Ω
- Alarm 2 inputs, 1 output
- Reset Yes
Event
- Basic Event Motion detection, video tampering alarm, exception, alarm input and output
- Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
- Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)
Deep Learning Function
- Face Capture Detects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face
- Perimeter Protection Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)
General
- Power 24 VAC, Max. 24 W (including max. 9 W for IR and max. 1.6 W for heater); PoE (802.3at)
- Dimension Ø 210 mm × 344.7 mm (Ø 8.27″ × 13.57″)
- Weight Approx. 3.0 kg (6.61 lb.)
- Material Metal
- Operating Condition -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
- Demist Yes
Approval
- EMC FCC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC (ICES-003: Issue 7);KC (KN 32: 2015, KN 35: 2015)
- Safety UL (UL 62368-1);CB (IEC 62368-1:2014+A11);CE-LVD (EN 62368-1:2014/A11:2017)
- Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
- Protection IP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage transient protection
