- Harmonized Flow Hub boosts static pressure and cooling efficiency.
- Harmonized blade edges smooth airflow and minimize turbulence.
- Triple Groove Fluid Dynamic Bearings provide durable, near silent operation.
| Dimensions | 140 × 140 × 30 mm |
| Bearing Type | Fluid Dynamic Bearing |
| Speed | 0 (0–20%) – 1600 (100%) RPM |
| Airflow | 85.18 CFM |
| Static Pressure | 2.19 mmH₂O |
| Noise Level | 30.8 dBA |
| Rated Voltage | DC 12V |
| Rated Current | 0.25 A |
| Frame & Blade Material | PBT + 30% Glass Fiber |
| Net Weight (Fan) | 230 g |
| MTTF | > 150,000h |
