The Grandstream 16 Port PoE Switch GWN7802P is a Layer 2+ managed network switch that allows small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable. It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks.
Offering intelligent dynamic PoE output, the Grandstream GWN7802P switch efficiently powers various PoE endpoints such as IP phones, IP cameras, and Wi-Fi access points. With multiple management options available, including the local web user interface, the GWN7802P switch provides flexibility. Additionally, support from GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform, enhances the series. Positioned as ideal managed network switches for small-to-medium businesses, the enterprise-grade GWN7800 series delivers comprehensive connectivity solutions.
Features
- 16 x Gigabit Ethernet ports and 4 Gigabit SFP ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port
- Supports deployment in IPv6 and IPv4 networks
- Provides quaternary binding of IP, MAC, VLAN & port; ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Local Web UI to manage switch, GWN.Cloud and GWN Manager, Grandstreams cloud and on-premise Wi-Fi management platform
- Built-in QoS allows for prioritization of network traffic.
Specifications:
- Gigabit Ethernet Ports: 16
- Gigabit SFP Ports: 4
- Console Port: Yes
- # of PoE Ports: 16
- Integrated Power Supply: 270W
- Max Output Power per PoE Port: 30W
- Max Total PoE Output Power: 240W
- PoE Standards: IEEE 802.3af/at
- Multicast: IGMP Snooping, MLD Snooping, MVR
- DHCP: DHCP server, DHCP relay, Option 82, 60,160 and 43
- Maintenance: CPU & memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup & restore, syslog, alert, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) & copper test
- Mounting: Desktop, wall-mount, or rack-mount (rack-mount brackets included)
- Fan: 1
Switching:
- 8K static, dynamic and filtering MAC addresses
- 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
- VLAN virtual interface
- GVRP (pending)
- 8 link aggregation groups
- Spanning tree, 16 instances for STP/RSTP/MSTP
QoS/ACL:
- Auto detection and prioritization of voice/video/RTP/SIP/other latency-sensitive packets (pending)
- Port priority
- Priority mapping
- Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ
- Traffic shaping
- Rate limit
- 1.5K ACL for Ethernet, IPv4 & IPv6
Security:
- User hierarchical management and password protection, HTTPS, SSH, Telnet
- 802.1X authentication
- AAA authentication including RADIUS, TACACS+
- Storm control
- Port isolation, port security, sticky MAC
- Filtering MAC address
- IP source guard, DoS attack prevention, ARP inspection
- DHCP Snooping
- Loop protection including BPDU protection, root protection and loopback protection
- Kensington Security Slot
