title: Gigabyte P550B 80+ Bronze Certified
date: 2022-02-19T21:23:56Z
modified: 2026-06-11T11:03:24Z
permalink: "https://tech.co.za/product/gigabyte-p550b-80-bronze-certified/"
type: product
status: publish
excerpt: ""
wpid: 431169
product_brand:
  - Gigabyte
product_type:
  - simple
product_visibility:
  - featured
product_cat:
  - Components
  - Power Supplies
featured_image: "https://tech.co.za/wp-content/uploads/2022/02/Gigabyte-P550B.png"
---

- 80 PLUS Bronze certified
- 120mm Silent Hydraulic Bearing (HYB) Fan
- Reliable flat cable
- Single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection
- 3 years warranty (Adjusted according to different regions)

- Model P550B
- Type Intel Form Factor ATX 12V v2.31
- PFC Active PFC(>0.9 typical)
- Input Voltage 100-240 Vac(full range)
- Input Current 8-4 A
- Input Frequency 60-50 Hz
- Output Capacity 550W
- Dimension 150 x 140 x 86 mm
- Fan Type 120mm Hydraulic Bearing (HYB) Fan
- 80 PLUS Bronze
- Efficiency 85% at typical load
- MTBF>100,000 hours
- Protection OVP/OPP/SCP/UVP/OCP/OTP
- Power Good Signal 100-500ms
- Hold Up Time>16ms
- Cable Type Flat, All black
- Connectors ATX/MB 20+4 Pin x 1 : 550mm\*1
    CPU/EPS 4+4 Pin x 1 : 600mm\*1
    PCI-e 6+2 Pin x 2 : 550mm+150mm\*1
    SATA x 6 : 500mm+120mm+120mm\*2
    4 Pin Peripheral x 3 + 4-Pin floppy x 1 : 500mm+120mm+120mm+120mm\*1
