| Technology |  |
| --- | --- |
| Projection System | 3LCD Technology, RGB liquid crystal shutter |
| LCD Panel | 0,76 inch with D10 |
| Image |  |
| Color Light Output | 5.000 Lumen- 3.800 Lumen (economy) In accordance with IDMS15.4 |
| White Light Output | 5.000 Lumen – 3.800 Lumen (economy) In accordance with ISO 21118:2020 |
| Resolution | WUXGA |
| Resolution Enhancement | Full HD |
| Aspect Ratio | 16:10 |
| On-Screen Pixel Count | 2,304,000 |
| Contrast Ratio | 15.000 : 1 |
| Light source | Lamp |
| Lamp | 300 W, 5.000 h durability, 10.000 h durability (economy mode) |
| Keystone Correction | Auto vertical: ±30 °, Auto horizontal ±20 ° |
| Colour Video Processing | 10 Bits |
| 2D Vertical Refresh Rate | 200 Hz – 240 Hz |
| Colour Reproduction | Upto 1.07 billion colours |
| Optical |  |
| Throw Ratio | 1,38 – 2,28:1 |
| Zoom | Manual, Factor:1 – 1,6 |
| Lens | Optical |
| Screen Size | 50 inches – 300 inches |
| Projection Distance Wide | 1,5 m ( 50 inch screen ), |
| Projection Distance Tele | 9 m ( 300 inch screen ), |
| Projection Lens F Number | 1,5 – 2 |
| Projection Lens Focal Length | 23 mm – 38,4 mm |
| Projection Lens Focus | Manual |
| Offset | 10 : 1 |
| Connectivity |  |
| USB Display Function | 3 in 1: Image / Mouse / Sound |
| Interfaces | USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in (2x), Composite in, RGB in (2x), RGB out, MHL, Jack plug out, Jack plug in (2x), Wireless LAN IEEE 802.11a/b/g/n/ac (optional) |
| Epson iProjection App | Ad-Hoc / Infrastructure |
| Advanced Features |  |
| Security | Kensington lock, Security bar, Control panel lock, Password lock, Padlock, Wireless LAN unit lock, Wireless LAN security, Password protection |
| 2D Colour Modes | Dynamic, Cinema, Presentation, sRGB, Blackboard, DICOM SIM |
| Other features | AV Mute Slide, Auto Power On, Automatic input selection, Automatic keystone correction, CEC compatible, Direct Power on/off, Document Camera Compatible, Fit to Screen, Freeze image, Gesture Presenter, Home Screen, JPEG Viewer, Long lamp life, MHL audio/video interface, Network administration, OSD copy function, PC Free, Projection App for Chromebook, Quick Corner, Slide show, Split-Screen-Function, iProjection App |
| Video Color Modes | Blackboard, Dynamic, Photo, Presentation, sRGB, DICOM SIM |
| Projector control | via: AMX, Crestron, Control4 |
| General |  |
| Power consumption | 341 Watt (Normal On-Mode), 266 Watt (Eco On-Mode), 405 Watt (Normal Peak-mode), 323 Watt (Eco Peak-Mode), 0,31 Watt (Energy saving standby) |
| Supply Voltage | AC 220 V – 240 V, 50 Hz – 60 Hz |
| Product dimensions | 377‎ x 291 x 110 mm (Width x Depth x Height) |
| Product weight | 4,6 kg |
| Noise Level | Normal:39 dB (A) – Economy:29 dB (A) |
| Supported Temperature | Operation 5° C – 40° C, Storage -10° C – 60° C |
| Supported Humidity | Operation 20% – 80%, Storage 10% – 90% If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling. If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance. |
| Included Software | EasyMP Monitor, EasyMP Multi PC Projection |
| Options | Air filter, Ceiling mount, Connection and control box, Document camera, External Speaker, HDBaseT Transmitter, Soft carry case, Spare lamp, Visualiser camera, WP System – ELPWP20, Wireless LAN unit, Wireless transmitter – ELPWT01 |
| Loudspeaker | 16 Watt |
| What’s in the box | HDMI Cable, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, Safety and support guide, Software (CD), User Manual (CD-ROM), Warranty document |
| Room Type / Application | Boardroom, Large Meeting Room / Auditorium |
| Positioning | Ceiling Mounted, Desktop |
| Colour | White |
