Specs
Capacity: 512Wh
Net Weight: Approximately 6kg
Dimensions: 270 x 260 x 196mm
AC Input: 220-240V~ 50Hz/60Hz, 660W Max
Solar Input: 11-50V 13A, 220W Max
Car Input: 12V/24V, 8A, 100W Max
USB-C Input/Output: 5/9/12/15/20V, 5A, 100W Max
DC Output: 12.6V, 10A/3A/3A, 126W Max
USB-A Output: 5V, 2.4A, 12W Max
AC Output: Pure Sine Wave, 500W total (surge 1000W), 230V ~ 50Hz/60Hz
Cell Chemistry: LFP
Cycle Life: 80%+ capacity after 3000 cycles
Discharge Temperature: -10°C to 45°C
Charge Temperature: 0°C to 45°C
Optimal Operating Temperature: 20°C to 30°C
Storage Temperature: -10°C to 45°C (20°C to 30°C is best)
DC5521 Output: 12.6V, 3A, 36W Max
App Control: Wi-Fi, Bluetooth
Capacity: 512Wh
Net Weight: Approximately 6kg
Dimensions: 270 x 260 x 196mm
AC Input: 220-240V~ 50Hz/60Hz, 660W Max
Solar Input: 11-50V 13A, 220W Max
Car Input: 12V/24V, 8A, 100W Max
USB-C Input/Output: 5/9/12/15/20V, 5A, 100W Max
DC Output: 12.6V, 10A/3A/3A, 126W Max
USB-A Output: 5V, 2.4A, 12W Max
AC Output: Pure Sine Wave, 500W total (surge 1000W), 230V ~ 50Hz/60Hz
Cell Chemistry: LFP
Cycle Life: 80%+ capacity after 3000 cycles
Discharge Temperature: -10°C to 45°C
Charge Temperature: 0°C to 45°C
Optimal Operating Temperature: 20°C to 30°C
Storage Temperature: -10°C to 45°C (20°C to 30°C is best)
DC5521 Output: 12.6V, 3A, 36W Max
App Control: Wi-Fi, Bluetooth
Warning:
Charging and discharging a battery multiple times a day will significantly deteriorate its performance. Please note the limitations of each battery technology:
- Lead-acid batteries can only be discharged up to 50% before irreversible damage occurs.
- Gel lead-batteries can often be discharged up to 70% before irreversible damage occurs.
- Lithium batteries can be fully discharged if they are protected by a Battery Management System.
Due to the above limitations, loss of battery capacity is not covered under warranty.
