title: Corsair 2500X Micro ATX Dual Chamber PC Case
date: 2024-11-05T15:44:58Z
modified: 2026-05-21T15:04:48Z
permalink: "https://tech.co.za/product/corsair-2500x-micro-atx-dual-chamber-pc-case/"
type: product
status: publish
excerpt: "The CORSAIR 2500X Mid-Tower Dual Chamber PC Case delivers exceptional airflow and cooling with fully mesh paneling and a dual chamber design for an organized, stunning build.\\n\\n    Dual chambers for a streamlined look\\n    Lots of customization options\\n    Compatible with reverse connector mATX & mITX motherboards\\n    Wide cooling flexibility"
wpid: 519000
product_brand:
  - Corsair
product_type:
  - simple
product_visibility:
  - featured
product_cat:
  - Components
  - Computer Cases
featured_image: "https://tech.co.za/wp-content/uploads/2024/11/CC-9011265-WWa.png"
---

Case Height: 376
Case Length: 469
Case Width: 304
Material: Steel, Tempered Glass, Plastic
Motherboard Support: Mini-ITX, Micro-ATX
Color: BLACK
Weight: 13.39
Radiator Compatibility: 120mm, 140mm, 240mm, 280mm, 360mm
Maximum GPU Length: 400mm
Maximum CPU Cooler Height: 180mm
Maximum PSU Length: 225mm
Compatible Liquid Coolers: H60, H100i, H115i, H150i (All Series)
Case Size: NA
Case Power Supply: ATX
Case Expansion Slots: 4 horizontal (4 vertical with accessory)
Case Front IO: (1x) USB 3.2 Gen 2 Type-C, (2x) USB 3.2 Gen 1 Type-A, (1x) Audio in/out
Case Window: Tempered Glass
Internal 3.5″ Drive Bays: 2
Internal 2.5″ Drive Bays: 2
Radiator Support – Top: 360mm, 280mm, 240mm
Radiator Support – Front: None (Glass Panel)
Radiator Support – Bottom: 360mm, 280mm, 240mm
Radiator Support – Side: 240mm
Radiator Support – Rear: 120mm
Fan Support – Top: 3x 120mm, 3x 140mm
Fan Support – Front: None (Glass Panel)
Fan Support – Bottom: 3x 120mm, 3x 140mm
Fan Support – Side: 2x 120mm
Fan Support – Rear: 1x 120mm
Front IO Motherboard Connections: 1x HD Audio; 1x USB 3.2 Gen1; 1x USB-3.2 Gen2 Type-E; 1x F\_PANEL
Reverse Connector Motherboard Support: Yes
Dust Filtration: Yes
RapidRoute Included: Compatible (Sold Separately)
Power Supply Shroud Dimensions: N/A
Left Side Panel: Tempered Glass
Right Side Panel: Mesh
Vertical Mount Support: Supported (Vertical Mount Kit Sold Separately)
