title: Cooler Master MasterFrame 360 Panorama ATX Case
date: 2026-02-03T11:51:17Z
modified: 2026-05-18T11:07:23Z
permalink: "https://tech.co.za/product/cooler-master-masterframe-360-panorama-s-atx-case/"
type: product
status: publish
excerpt: Cooler Master MasterFrame 360 Panorama ATX Case
wpid: 569390
product_brand:
  - Cooler Master
product_type:
  - simple
product_cat:
  - Computer Cases
featured_image: "https://tech.co.za/wp-content/uploads/2026/02/MasterFrame-360-Panoramaa.jpg"
---

| Color | Black |
| --- | --- |
| Materials – Exterior | SGCC |
| Materials – Side panel (Right / Left) | TG / TG​ |
| Dimensions (L x W x H) | 549 x 291 x 581 mm (Incl. Protrusions), 511 x 291 x 581 mm (Excl. Protrusions) |
| Volume | 86 L (w/o panel, protrusions and feet), 93 L (with panel, protrusions and feet) |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX, BTF (ATX) |
| Power Supply Support | ATX |
| PCI Expansion Slots | 3.5 |
| Drive bay support – 3.5″ Drive Bays |  |
| Drive bay support – 2.5″ / 3.5″ Drive Bays (or SSD) | 1x HDD or 2x SSD |
| Preinstalled Drive bay – 3.5″ Drive Bay (remark Toolfree quantity) / 2.5″ Drive Bay(or SSD)(remark Toolfree quantity) | 1x HDD or 2x SSD |
| I/O Panel – USB Ports | 2x USB 3.2 Gen 1 Type-A 5G​, 1x USB 4.0 Gen 2×2 Type-C 20G |
| I/O Panel – Audio In / Out | 1x 3.5mm Headset Jack (Audio+Mic) |
| Fan Support – Top | 6x 120mm, 2x 140mm, 2x 180mm, 2x 200mm |
| Fan Support – Bottom | 6x 120mm, 2x 140mm, 2x 180mm, 2x 200mm |
| Radiator Support – Top | 120 / 140 / 240 / 280 / 360 mm (maximum thickness clearance 75mm) |
| Radiator Support – Bottom | 120 / 140 / 240 / 280 / 360 mm (maximum thickness clearance 75mm)​ |
| Dust Filters | Mesh Only (Removable Filters) |
| Other electronic components | 1x PCI-e 5.0 Riser / 2x ARGB spotlight |
| Maximum Dimensions for Front Collectibles Display (H x W x D) | 328 x 290 x 110 mm |
