title: Cooler Master CMP320 MATX Mesh Geode panel Case
date: 2023-07-13T17:37:51Z
modified: 2026-05-05T16:44:55Z
permalink: "https://tech.co.za/product/cooler-master-cmp320-matx-mesh-geode-panel-case/"
type: product
status: publish
excerpt: ""
wpid: 473011
product_brand:
  - Cooler Master
product_type:
  - simple
product_visibility:
  - featured
  - outofstock
product_cat:
  - Components
  - Computer Cases
featured_image: "https://tech.co.za/wp-content/uploads/2023/07/CP320-KGNN-S00a.png"
---

Model Number: CP320-KGNN-S00
Exterior Color: Black
Materials – Exterior: Steel, Plastic
Materials – Left Side Panel: Tempered Glass
Dimensions (L x W x H): 445.5 x 204 x 425mm (Incl. Protrusions), 431.8 x 204 x 410mm (Excl. Protrusions)
Volume: 38.52L (Excl. Protrusions)
Motherboard Support: Mini ITX, Micro ATX
Expansion Slots: 4
2.5″ / 3.5″ Drive Bays (Combo): 2
2.5″ Drive Bays: 2
I/O Panel: 1x USB 3.2 Gen 1 Type-A, 1x USB 2.0, 1x 3.5mm Headset Jack (Audio+Mic)
ARGB Controller: ARGB Fans Hub
Pre-installed Fans – Front: 2x CF120 ARGB
Fan Support – Top: 2x 120mm, 2x 140mm
Fan Support – Front: 2x120mm/3x120mm (\*Installed inside the case only)
Fan Support – Rear: 1x 120mm
Radiator Support – Top: 120mm, 140mm, 240mm, 280mm (\*Recommend AIO tubes face rear to avoid interference)
Radiator Support – Front: 120mm, 240mm
Radiator Support – Rear: 120mm
Clearance – CPU Cooler: 163.5mm
Clearance – PSU: 160mm
Clearance – GFX: 365mm (without front fans & radiator)
Cable Routing: 16.5mm
Dust Filters: Top, Bottom
Power Supply Support: Bottom Mount, ATX
