Introducing the Antec CX500M Gaming Chassis, which is designed for gamers who want both style and performance. Its panoramic design provides a sleek, transparent appearance that highlights your hardware beautifully. The tool-free glass side and front panels feature a clip design for easy and safe installation, while the bottom mesh exterior improves cooling efficiency and prevents heat buildup. The CX500M allows for up to 9 fans and a 360mm water cooling radiator on top, ensuring rapid heat dissipation and optimal performance.

The CX500M has a 5-slot PCIe design that improves graphics card compatibility and provides more cooling space, reducing the risk of overheating. Additional features include a removable hard drive cage, magnetic top and bottom dust filters for clean air intake, and a Type-C 3.2 Gen 2 port for fast data transfer. It includes two 120mm reverse blade fans on the sides and one 120mm fan in the back, which are pre-connected for easy setup. Enhance your gaming experience with the Antec CX500M Gaming Chassis.

### FEATURES:

- Panoramic 270° design for a transparent and sleek look.
- Tool-free glass side and front panels with a clip design for easy and safe installation.
- Vertical airflow supports up to 9 fans, speeding up heat dissipation.
- Includes a Type-C 3.2 Gen 2 port for high-speed data transfer.
- Top and Bottom Magnetic Dust Filters

### SPECIFICATIONS:

- Form Factor: Mini Tower
- Materials: Steel + Glass
- Mainboard Support: Micro-ATX, ITX
- Front Access & Controls: Power, LED On/Off , USB3.0 x 2 , Type-C 3.2 Gen 2 x 1, Headphone/Mic Combo Jack
- Side Panel: Tempered Glass
- Drive Bays:
    - 3.5″/2.5″: 2/1
    - 2.5″: 1
- Expansion Slots: 5
- Fan Support:
    - Top: 3 x 120mm/2 x 140mm
    - Side: 2 x 120mm
    - Power Supply Shroud: 3 x 120mm
    - Rear: 1 x 120mm
- Included Fan(s):
    - 2 x 120mm fixed mode RGB reverse fans on right side
    - 1 x 120mm fixed mode RGB fan in rear
- Radiator Support:
    - Top: 120/140/240/280/360mm
- Clearance:
    - Max GPU Length: ≤415mm
    - Max CPU Cooler Height: ≤165mm
    - Max PSU Length: ≤210mm (With HDD), ≤270mm (Without HDD)
    - Cable Routing Space: ≤ 23mm
- Dust Filter: Top / Bottom
- Colour: White
- Product Dimensions: 43.6 x 21 x 44.6 cm
- Product Weight: 6340g

### WHAT’S IN THE BOX:

- Antec CX500M Micro-ATX | ITX ARGB Mini-Tower Gaming Chassis – White x1
