AMD Ryzen™ 7 5800X3D | 8 Cores / 16 Threads | 3.4GHz Base, up to 4.5GHz Boost | 96MB L3 (3D V-Cache™) | Socket AM4 | DDR4 | PCIe 4.0
Quick Specs
- Game at the top of the AM4 platform with AMD’s 3D V-Cache™ technology
- Power through with 8 Zen 3 cores and 16 threads
- Boost up to 4.5 GHz when your games and apps demand it
- Tap into a massive 96MB of L3 cache for higher frame rates
- Drop straight into existing AM4 boards with DDR4 and PCIe 4.0
The Ultimate AM4 Gaming Processor
The AMD Ryzen™ 7 5800X3D is the ultimate gaming processor for the DDR4 platform, and it’s built around AMD’s game-changing 3D V-Cache™ technology. By stacking a huge 96MB of L3 cache onto its 8-core, 16-thread Zen 3 design, it feeds the CPU more game data closer to the cores — delivering higher frame rates in the titles that matter to gamers across South Africa, without needing a brand-new platform.
Zen 3 Performance, Ready to Boost
Built on the proven Zen 3 architecture, the 5800X3D runs at a 3.4 GHz base clock and boosts up to 4.5 GHz with Precision Boost 2, so it stays responsive whether you’re gaming, streaming or tackling everyday productivity. With 8 cores and Simultaneous Multithreading (SMT) for 16 threads, plus a 512KB L1 / 4MB L2 cache hierarchy, it has the muscle for serious multitasking as well as high-refresh gaming.
A Smart, Easy Upgrade for AM4 Builds
One of the 5800X3D’s biggest strengths is its socket AM4 compatibility. It works with X570, X470, B550, B450 and A520 chipsets, making it a superb drop-in upgrade for existing AM4 systems — often with just a BIOS update. It supports dual-channel DDR4 up to 128GB (DDR4-3200), PCIe® 4.0, and even ECC memory with compatible motherboards, so you get modern connectivity without the cost of a full platform change.
Built for Modern Gaming and Cool Operation
Supporting AMD 3D V-Cache™, Windows® 11 gaming and AMD Ryzen™ VR-Ready Premium, the 5800X3D is engineered for today’s most demanding experiences. It’s manufactured on TSMC’s 7nm process with a 105W default TDP and a 90°C maximum operating temperature. No cooler is included in the box, and AMD recommends a liquid cooler for optimal performance — so pair it with a capable AIO to keep it running at its best.
FEATURES:
- AMD 3D V-Cache™ technology with a massive 96MB L3 cache for higher gaming frame rates
- 8 Zen 3 cores and 16 threads (Simultaneous Multithreading)
- 3.4 GHz base clock, boosting up to 4.5 GHz with Precision Boost 2
- Socket AM4 compatibility with X570, X470, B550, B450 and A520 chipsets
- Dual-channel DDR4 support up to 128GB (DDR4-3200), with ECC support on compatible boards
- PCIe® 4.0 connectivity with NVMe boot and RAID 0/1/10 support
- Supports Windows® 11 Gaming and AMD Ryzen™ VR-Ready Premium
- Built on TSMC 7nm FinFET process technology
- Unlocked for tuning, with a broad set of supported instruction extensions
- Cooler not included; liquid cooler recommended for optimal performance
SPECIFICATIONS:
- Name: AMD Ryzen™ 7 5800X3D
- Family: Ryzen 7 (Ryzen 5000 Series)
- Processor Architecture: Zen 3
- Former Codename: Vermeer
- CPU Socket: AM4
- # of CPU Cores: 8
- # of Threads: 16
- Multithreading (SMT): Yes
- Base Clock: 3.4 GHz
- Max. Boost Clock: Up to 4.5 GHz
- CPU Boost Technology: Precision Boost 2
- L1 Cache: 512 KB
- L2 Cache: 4 MB
- L3 Cache: 96 MB
- Default TDP: 105W
- Max. Operating Temperature (Tjmax): 90°C
- Supporting Chipsets: X570, X470, B550, B450, A520
- Instruction Set: x86-64
- System Memory Type: DDR4
- Memory Channels: 2
- Max. Memory: 128 GB
- Max. Memory Speed: DDR4-3200 (2x1R / 2x2R)
- ECC Support: Yes (requires motherboard support)
- PCI Express® Version: PCIe® 4.0
- Native USB: 4 x USB 3.2 Gen 2 (10 Gbps)
- Native SATA Ports: 2
- Processor Technology (CPU Cores): TSMC 7nm FinFET
- Graphics: Discrete graphics card required
- Thermal Solution (PIB): Not included
- Recommended Cooler: Liquid cooler recommended for optimal performance
- Operating System Support: Windows 11 / Windows 10 (64-bit), RHEL x86 64-bit, Ubuntu x86 64-bit
WHAT’S IN THE BOX:
- AMD Ryzen™ 7 5800X3D Gaming Processor x1
Why AMD?
AMD Ryzen™ processors have earned a loyal following among gamers and creators worldwide for delivering exceptional performance and value. The Ryzen™ 7 5800X3D is a standout — a pioneering 3D V-Cache™ chip that remains one of the best gaming CPUs you can drop into an AM4 board. For South African gamers looking to get the most from an existing platform, it’s a smart, high-impact upgrade backed by AMD’s reputation for quality.
