General Specifications
Platform
Desktop
Market Segment
Mainstream Desktop
Product Family
AMD Ryzen⢠Processors
Product Line
AMD Ryzen⢠5 Desktop Processors
Consumer Use
Yes
Regional Availability
Global, China, NA, EMEA, APJ, LATAM
Former Codename
“Cezanne”
Architecture
“Zen 3”
# of CPU Cores
6
Multithreading (SMT)
Yes
# of Threads
12
Max. Boost ClockÂ
Up to 4.2GHz
Base Clock
3.6GHz
L1 Cache
384KB
L2 Cache
3MB
L3 Cache
16MB
Default TDP
65W
Processor Technology for CPU Cores
TSMC 7nm FinFET
CPU Compute Die (CCD) Size
180mm²
Package Die Count
1
Unlocked for OverclockingÂ
Yes
CPU Socket
AM4
Socket Count
1P
Supporting Chipsets
X570
X470
X370
B550
B450
B350
A520
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB)
AMD Wraith Stealth
Max. Operating Temperature (Tjmax)
90°C
Launch Date
4/4/2022
*OS Support
Windows 11 – 64-Bit Edition
Windows 8.1 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-CÂŽ Support
Yes
Native USB 4 (40Gbps) Ports
0
Native USB 3.2 Gen 2 (10Gbps) Ports
4
Native USB 3.2 Gen 1 (5Gbps) Ports
0
Native USB 2.0 (480Mbps) Ports
0
Native SATA Ports
2
PCI ExpressÂŽ Version
PCIe 3.0
Native PCIeÂŽ Lanes (Total/Usable)
24/20
Additional Usable PCIe Lanes from Motherboard
AMD X570
16x Gen 3
AMD X470
2x Gen 3
AMD X470
8x Gen 2
NVMe Support
Boot, RAID0, RAID1, RAID10
System Memory Type
DDR4
Memory Channels
2
Max. Memory
128GB
System Memory Subtype
UDIMM
System Memory Specification
Up to 3200MHz
Max Memory Speed
2x1R
DDR4-3200
2x2R
DDR4-3200
4x1R
DDR4-2933
4x2R
DDR4-2667
ECC Support
No
Graphics Capabilities
Integrated Graphics
No
Graphics Model
Discrete Graphics Card Required
