- RGB LED design on the front and side of the air cooler adds a stylish flair to your rig
- Comes equipped with 12cm Addressable RGB fan with translucent fan blades
- Comes with built-in RGB lighting effects and compatibility with Addressable RGB motherboards or hubs
- Heat Core Touch Technology with 4 ultra-efficient thermal heat pipes
- Cover on the side of the air cooler achieves a unidirectional air flow, improving heat dissipation
- Upgraded high efficiency fins for optimal thermal performance
- Black coating on fins improves efficiency of heat dissipation
- TDP (Thermal Design Power) up to 145W
| Model | Cylon 4F |
| Base Material | Aluminum block with HCTT Heat Core Touch Technology |
| Fin Material | Aluminum |
| Heat pipe | Dia. 6mm x 4 |
| Dimension | 126.5 x 76 x 160mm |
| TDP(Thermal Design Power) | 145 |
| Fan | |
| Speed | 800-1800 rpm |
| Connector | PWM 4-Pin |
| Dimension | 120 x 120 x 25mm |
| Bearing Type | Hydraulic Bearing |
| Started Voltage | 5V |
| Rated Voltage | 12V |
| Rated Current | 0.6 A |
| Power Consumption | 7.2 Watts |
| Air Flow | 26.1-52.5 CFM |
| Noise | 14-26 dBA |
| MTBF (Mean Time Before Failure) | 60000 hrs. |
| Socket | LGA 2066 / 2011 / 1700 / 1200 / 115X AM5/AM4/AM3+/AM3/AM2+/AM2/FM2/FM1 |
| For compatibility, check that LGA1700/AM5 is listed as a supported bracket on the packaging. | |
