Chipset
CPU: Dual core,MIPS interAptivTM 900MHz+RLX5281 500MHz
Interfaces
LAN port: 4 x GE port
PON port: 1
VoIP(POTS): 1
USB: 1
Reset: 1
Power switch: 1
WPS: 1
Wi-Fi 6
Standard: IEEE 802.11 a/b/g/n/ac/ax
Speed: 574 Mbps @2.4GHz 2T2R +1200 Mbps @ 5.8GHz 2T2R
Antenna: 4 x External
Gain: 5dBi
xPON
Wavelength: 1310nm/1490nm
Standard GPON: Upstream rate up to 1.244 Gbit/s,
downstream rate up to 2.488 Gbit/s
EPON: Upstream rate up to 1.244 Gbit/s,
downstream rate up to 1.244 Gbit/s
Sensitivity: ≤-28dBm
Emission Power: 1dBm<P<4dBm
Distance: 20 km
Connector: SC/UPC or SC/APC
Support
Protocols:
ITU-T G.984/G.988
IEEE 802.3ah, YD/T 1475-2006
IEEE 802.1D，Spanning Tree
IEEE 802.1Q, VLAN
IEEE 802.1w, RSTP
IGMP v1/v2/v3
ITU-T Y.1291
VoIP: SIP
Access Mode; Optional: PPPoE, Bridge, IPoE
Management: OMCI, TR-069
Algorithm: SP/WRR/SP+WRR
Networking: NAT/NAPT
IPv4 & IPv6 Dual Stack
DNS Relay
VPN Transparent, PPTP, L2TP
Security
Encryption: AES128(GPON) & Triple churning(EPON)
Data Protection: FEC(Forward Error Correction)
Authentication: CHAP, EAP
Firewall:
Port Forwarding
MAC Filtering
DoS Attack Prevention
