Conductor
Material: CCA (Copper-clad aluminium)
Size: 23 AWG
Construction: 1 / 0.56mm ± 0.01mm
Resistance: ≤ 19.5 Ω / 100M at 20℃
Insulation
Material: HDPE
Avg. Thickness: 0.20mm
Min. Thickness: 0.19mm
Diameter: 0.95 ± 0.03 mm
Resistance: Min.5000 mega-Ω / km at 20℃
Dielectric Test: 1000V DC/1min; No Breakdown
Inner Layer Direction: S
Pitch: 25mm Underneath
Outside Layer
Direction: S
Pitch: 200mm Underneath
Separator/Spline
Material: Polyethylene
Construction: 4.0 x 4.0 x 0.4mm
Shielding
Material: Mylar
Coverage: 100% coverage with 25% overlapping
Drain Wire: 1 / 0.4mm CCA
Material: Aluminium / Mylar
Coverage: 100% coverage with 25% overlapping face inside
Material: Aluminium magnesium wire
Construction: 64 * 0.12 AL
Jacket
Material: PVC
Avg. Thickness: 0.55mm
Min. Thickness: 0.50mm
Diameter: 6.4 ± 0.15mm
Other Install Temp: -20°C ~ +60°C
