Operational
Light Source: 650 nm visible laser diodes
Depth of Field: 5 mil: 40 – 90 mm
7.5 mil: 0 – 150 mm
10 mil: 0 – 180 mm
13 mil: 0 – 200 mm
20 mil: 0 – 280 mm
Note: DOF may vary depending on environment condition and barcode quality.
Scan Lines: 20
Scan Pattern: 5 directions of scan field
Scan Rate: 1400 scans per second/74 scans per second(single-line)
Print Contrast: 30% @ UPC/EAN 100%
Indicator: Two-color LED (blue & red)
Programmable Operation: Beeper tone & volume
System Interface: HID USB
Physical Characteristics
Dimensions H x W x L: 110.9 × 70.0 × 65.8 mm (on fixed stand)122.2~253.0 × 74.0 × 7120.3~163.3 × mm (on optional cradle)
Weight (g): 200 g (on stand)350 g (on optional cradle)
Cable: Standard 2M straight
Power
Input Voltage: 5 VDC ± 10%
Power Consumption: 1.0 watts
Operating Current: 200 mA @ 5 V
Regulatory
Laser Class: CDRH Class IIa; IEC 60825: Class 2
EMC: CE & FCC DOC compliant, VCCI, BSMI
