The Ubiquiti UniFi Device Bridge UDB is a high-performance WiFi bridging PoE adapter designed for seamless connectivity and reliable performance. With its compact form factor, the UDB simplifies bridging between networks, enabling smooth wireless communication in point-to-point or point-to-multipoint setups. Ideal for businesses, installers, or home networks, the UDB ensures stable, high-speed data transfer with low latency. Power your devices effortlessly with PoE support for easy installation.
| Dimensions | 130 x 55 x 34 mm |
| WiFi Standard | WiFi 5 |
| Spatial Streams | 2 |
| Mounting Locations | Wall, table |
| Mounting | Wall (Included) |
| Power Method | 100—240V AC, 0.45A Max., 50/60 Hz |
| Performance | |
| MIMO | 5 GHz – 2 x 2 |
| Max. Data Rate | 5 GHz – 866.7 Mbps (BW80) |
| Antenna Gain | 5 GHz – Internal: 5 dBi, External omni: 4 dBi, 360° x 30° |
| Max. TX Power | 5 GHz – 21 dBm |
| Supported Data Rates | 802.11ac (WiFi 5) – 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) |
| 802.11n – 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) | |
| 802.11a – 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| Wireless Security | WPA2 AES |
