The PowerBeam 5AC Gen 2 directs RF energy in a tighter beamwidth. With the focus in one direction, the PowerBeam 5AC Gen 2 blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Hardware | |
Networking interface | (1) GbE RJ45 port |
Power method | Passive PoE 2-pair (4, 5+; 7, 8 return) |
Power supply | 24V, 0.5A gigabit PoE adapter (Included) |
Supported voltage range | 20—27V DC |
Max. power consumption | 8.5W |
ESD/EMP protection | Air/contact: ± 24 kV |
LEDs | Power, Ethernet, (4) signal strength |
Salt fog test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 |
Vibration test | IEC 68-2-6 |
Temperature shock test | IEC 68-2-14 |
UV test | IEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4 |
Wind-driven rain test | ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5 |
Ambient operating temperature | -40 to 70° C (-40 to 158° F) |
Ambient operating humidity | 5 – 95% noncondensing |
Certifications | CE, FCC, IC, RoHS |
