- 4MP Super-High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
- 24h Full-Color: Obtain 24-hour color details, even in pitch-black conditions, with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
- Powerful Pan Tilt: Customized patrol routes and auto tracking provide more intelligent options to monitor key areas and improve security within your property.
- Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
- Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you’ve set, obstructs the camera, or removes/abandons objects.
- Automatic Tracking: Continues following specified moving persons or vehicles with Pan Tilt cameras intelligently analyzing the image.
- Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
- Two-Way Audio: Intelligently detect activities, inform you instantly and response automatically by smart detection and two-way audio.
- H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
- Smart Video Enhancement: VIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
- IP66 Waterproof: Reliable IP66 for stable outdoor performance.
- PoE/12V DC: Two types of power supply not only give you more convenience but also make your wiring remarkably easy.
- Flexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 256GB).
CAMERA
Image Sensor: 1/3” Progressive Scan CMOS
Lens: Fixed focal lens (4 mm)
Day/Night Switch: Unified/ Scheduled/ Auto
Digital Noise Reduction: 3D DNR
WDR: DWDR
Weatherproof Rating: IP66
IR Working Distance: 30m
Pan/Tilt Range: Pan: 0° to 350°, Tilt: 0° to 120°
Shutter Speed: 1/3 to 1/10000 s
Aperture: 4 mm: F1.6
Lens Mount: M12
Illumination Distance: 30 m
Viewing Angle: (4mm) Horizontal FOV: 80°, Vertical FOV: 43.2°, Diagonal FOV: 94.2°
Digital Zoom: Yes
Slow Shutter: Yes
Minimum Illumination: Color: 0.005 Lux; 0 Lux with IR/white light
Day/Night Mechanism: IR Cut Filter
NETWORK
Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIF: Yes
API: Open Network Video Interface (Profile S)
Simultaneous Live View: Up to 6 Channels
Client: VIGI App, VIGI Security Manager, VIGI NVR, Web
Web Browser:
– Google Chrome® 57 and above
– Firefox® 52 and above
– Safari® 11 and above
– Microsoft® Edge 91 and above
Cloud: Yes
Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Network Storage: NAS (NFS, SMB/ CIFS)
GENERAL
Operating Temperature : -30–60 °C
Storage Temperature: -40–60 °C
Operating Humidity: 95% or Less (Non-Condensing)
Storage Humidity: 95% or Less (Non-Condensing)
Weight: 195g
Package Contents:
– VIGI Network Camera
– Quick Start Guide
– Waterproof Cable Attachments
– Mounting Accessories
Dimensions( H X W X D ): 120 × 172 × 198 mm
Material: Plastic
General Features: Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Power Requirements:
– 12V DC ± 5%, 5.5mm Coaxial Power Plug
– PoE (802.3af/at, class 0)
Net Weight: 0.62 Kg
Gross Weight: 0.98 Kg
Power Consumption:
– 12V DC: Max 14W
– PoE: Class 4
Power Supply:
– 12V DC ± 5%, 5.5mm Coaxial Power Plug
– PoE (802.3af/at, class 4)
Protection: IP66
Product Dimensions (L x W x H): 120 × 172 × 198 mm
Certifications: CE, RCM, BSMI, VCCI, RoHS, NTRA, KC
INTERFACES
Network Interface: 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Audio Input: Built-in Microphone
Audio Output: N/A
Alarm: N/A
Reset Button: Yes
Power: DC Power Port
Button: Reset Button
Slot: Micro SD card
On-board Storage:
– Built-In Memory Card Slot, Support MicroSD Card,
– Up to 256 GB
Built-in Microphone: Yes
Built-in Speaker: Yes
Audio: N/A
ALARM AND EVENT MANAGEMENT
Smart Event: Area Intrusion Detection, Line-Crossing Detection, People Detection
Basic Event: Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
Alarm Linkage: Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Linkage Method: N/A
Output Notification: Message Push
VIDEO/IMAGE
Video Compression:
– Main stream: H.265+/H.265/H.264+//H.264
– Sub-Stream: H.265/H.264
H.264 Type: Main Profile/High Profile
H.264+: Main Stream Supported
H.265 Type: Main Profile
H.265+: Main Stream Supported
Frame Rate & Resolutions:
– Main Stream
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720
– Sub-Stream
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 640×480, 352×288, 320×240
Max. Resolution: 2560 X 1440
Video Streaming:
Main Stream
Sub-Stream
Image Settings:
– Mirror, Brightness, Contrast, Saturation, Sharpness,
– Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation (90°/270°)
Image Enhancement: BLC/3D DNR/HLC/SmartIR
Video Bit Rate:
– Main Stream: 256 Kbps to 4 Mbps
– Sub-Stream: 64 Kbps to 512 Kbps
Day/Night Switch: Day/Night/Auto/Schedule-Switch
Privacy Mask: Up to 4 Masks
SMART FEATURE-SET
Smart Event:
– Human & Vehicle Classification, Area Intrusion
– Detection, Line-Crossing Detection, People
– Detection, Vehicle Detection, Region Entering
– Detection, Region Exiting Detection, Object
– Abandoned Detection, Object Removal Detection
Basic Event: Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
Linkage Method: N/A
Region of Interest: 1 Region
Alarm Linkage: Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Output Notification: Message Push
AUDIO
Audio Communication: Two-Way Audio
Audio Input: Yes
Audio Output: Yes
Audio Compression: Yes
Audio Sampling Rate: 8KHz
Environment Noise Filtering: Yes
Audio Bit Rate: 64 Kbps(G.711 alaw)
PTZ
Pan/tilt Range: Pan: 0° to 350°, Tilt: 0° to 120°
Pan/tilt Speed:
– Pan Speed:
Configurable from 1° to 55°/s; Preset Speed: 55°/s
– Tilt Speed:
Configurable from 1° to 40°/s, Preset Speed 40°/s
Manual Control Speed: Configurable from 8° to 35°/s
Presets: 300
Patrol Scan: 8 patrols, up to 8 presets for each patrol
Power-off Memory: Yes
Park Action: Yes
3D Positioning: Preset, Patrol Scan
ILLUMINATOR
IR LED:
– Quantity: 2
– Range: 30m
– Wavelength: 850nm
White LED:
– Quantity: 2
– Range: 30m
Illuminator On/Off Control: Auto/Scheduled/Always on/Always off
LENS
Type: Fixed Focal Lens
Focal Length: 4 mm
Aperture: F1.6
FOV:
4mm:
– Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°
Lens Mount: M12
DORI Distance:
4 mm:
– Detect: 80 m (262 ft)
– Observe: 33 m (109 ft)
– Recognize: 16 m (52 ft)
– Identify: 8 m (26 ft)
ANGLE ADJUSTMENT (MANUAL)
Range:
– Pan: 0° to 348°
– Tilt: 0° to 120°
VIDEO
Max. Resolution: 2560 X 1440
Main Stream:
– Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2560×1440, 2304×1296, 2048×1280, 1920×1080
– Sub-Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
640×480, 352×288, 320×240
Bit Rate Control: CBR, VBR
Video Compression:
– Main Stream: H.265+/H.265/H.264+/H.264
– Sub-Stream: H.265/H.264
H.264 Type: Main Profile/High Profile
H.264+: Main Stream Supported
H.265 Type: Main Profile
H.265+: Main Stream Supported
Video Bit Rate:
– Main Stream: 256 Kbps to 4 Mbps
– Sub-Stream: 64 Kbps to 512 Kbps
Image Settings: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software
Image Enhancement: BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range: DWDR
SNR: ≥ 52 dB
Image Parameters Switch: Yes
Privacy Mask: Up to 4 Masks
ROI: 1 Region
OSD Setting: Yes
