- 10G Lightning-Fast Uplink: Enjoy high-bandwidth connectivity and non-blocking switching capacity with four 10 Gbps SFP+ slots.
- PoE+ Output with 500 W Power Budget: Design your optimal network layout with forty-eight 802.3af/at PoE+ gigabit ports.*
- Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management.
- Abundant L2 and L2+ Features: It supports a complete lineup of L2 and L2+ features, including Static Routing, enterprise-level QoS, and IGMP Snooping.
- Robust Security Strategies: Helps protect LAN area investment with integrated IP-MAC-Port Binding, ACL, Port Security, and 802.1X Authentication.
- Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities.
HARDWARE FEATURES
Interface:
– 48× 10/100/1000 Mbps RJ45 PoE+ Ports
– 4× 10G SFP+ Slots
– 1× RJ45 Console Port
– 1× Micro-USB Console Port
Fan Quantity: 3
Power Supply: 100-240 V AC~50/60 Hz
PoE+ Ports(RJ45):
– Standard: 802.3at/af compliant
– PoE+ Ports: 48 Ports, up to 30 W per port
– Power Budget: 500 W*
Dimensions ( W x D x H ): 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)
Mounting: Rack Mountable
Max Power Consumption:
– 49.19 W (110V/60Hz) ( no PD device connected)
– 635.7 W (110V/60Hz) ( with 500 W PD device connected)
Max Heat Dissipation:
– 167.85 BTU/hr (110 V/60 Hz) (no PD connected)
– 2169.2 BTU/hr (110 V/60 Hz) (with 500 W PD connected)
