- 24 10/100M RJ45 ports.
- Innovative energy-efficient technology saves power up to 75%
- Supports MAC address self-learning and auto MDI/MDIX.
- Standard 13-inch steel case.
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Interface: 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: Yes
Power Supply: 100-240VAC, 50/60Hz
Dimensions ( W x D x H ): 11.6*7.1*1.7 in. (294*180*44 mm)
Mounting: Rack Mountable
Max Power Consumption: 3.19W(220V/50Hz)
Max Heat Dissipation: 10.88BTU/h
PERFORMANCE
Switching Capacity: 4.8Gbps
Packet Forwarding Rate: 3.57Mpps
MAC Address Table: 8K
Buffer Memory: 2Mb
Green Technology: Innovative energy-efficient technology saves power up to 75%
Transfer Method: Store-and-Forward
