- IEEE 802.3af compliant
- Auto-determine the necessary power requirements
- Gigabit speed support
- Plug-and-Play, requires no configuration
HARDWARE FEATURES
Interface:
– 2 10/100/1000Mbps RJ45 Port
– AUTO Negotiation/AUTO MDI/MDIX
– 1 48VDC POWER INPUT PORT
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
– EIA/TIA-568 100Ω STP (Max 100m)
– 100BASE-TX: UTP category 5, 5e cable (Max 100m)
– EIA/TIA-568 100Ω STP (Max 100m)
– 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Power Supply: 15.4W (Max. 48VDC)
LED Indicator: PWR
Dimensions ( W x D x H ): 3.22.10.9 in.(80.85424 mm)
