TP-Link EC120-F5 AC750 Wireless Dual Band Router

HARDWARE FEATURES Interface 4 10/100Mbps LAN ports
1 10/100Mbps WAN port
Power Supply 9VDC/0.6A Dimensions ( W x D x H ) 230 x 144 x 35mm Antenna 2 × 2.4GHz Antennas
1 × 5GHz Antenna

WIRELESS FEATURES
Frequency	5GHz: Europe (ETSI) 5.18~5.24 GHz (CH36~48) (without DFS) North America (FCC, IC) 5.18~5.24 GHz (CH36~48) (without DFS) 2.4GHz: Europe (ETSI) 2.412~2.472 GHz (CH1~CH13) North America (FCC, IC) 2.412~2.462 GHz (CH1~ CH11)
Signal Rate	300Mbps(2.4GHz) 433Mbps(5GHz)
Reception Sensitivity	5GHz: 11a 54M: -73dBm; 11ac VHT20 MCS8: -66dBm; 11ac VHT40 MCS9: -61dBm; 11ac VHT80 MCS9: -58dBm. 2.4GHz: 11g 54M: -75dBm; 11n HT20 MCS7: -73dBm; 11n HT40 MCS7: -70dBm
Wireless Security	WEP,WPA / WPA2,WPA-PSK/WPA2-PSK encryption
Transmission Power	CE: <20dBm(2.4GHz), <23dBm(5GHz) FCC: <30dBm

SOFTWARE FEATURES
Quality of Service	WMM, Bandwidth Control
Security	DoS, SPI Firewall, IP Address Filter/MAC
Management	Access Control, Local Management, Remote Management
DHCP	Server, DHCP Client List, Address Reservation
Port Forwarding	Virtual Server, Port Triggering, UPnP, DMZ
Access Control	Parental Control, Local Management Control, Host list, Access Schedule, Rule Management

OTHERS
Certification	CE, FCC, RoHS
Package Contents	AC750 Wireless Dual Band Router Archer C20 Power Adapter RJ45 Ethernet Cable Quick Installation Guide
Environment	Operating Temperature: 0℃–40℃ (32℉–104℉) Storage Temperature: -40℃–60℃ (-40℉–140℉) Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing
