- Blazing-Fast Wi-Fi 6 Speeds – 574Mbps on 2.4GHz plus 4804Mbps on 5.0GHz
- Integrated into Omada SDN – Supporting centralised cloud management, ZTP and more
- 160MHz Channel – Double the data at peak transmission times on a single stream
- Advanced Features – Supports seamless roaming, Omada Mesh and more
- Supports both 802.3at PoE+ and DC (Adapter Not Included) Power Supply – For flexible installations
| HARDWARE FEATURES | |
| Interface | 1× 2.5 Gigabit Ethernet (RJ45) Port (Supports IEEE802.3at PoE) |
| Button | Reset |
| Power Supply | 802.3at PoE |
| DC12V 2A (Power Adapter Not Included) | |
| Max. Power Consumption | 20.8W |
| Dimensions (W × D × H) | 220 × 220 × 32.5mm |
| Antenna | Internal Omni |
| 2.4GHz: 2× 4dBi | |
| 5.0GHz: 4× 5dBi | |
| Bluetooth | Yes |
| Mounting | Ceiling / Wall-Mounting (Kits Included) |
| WIRELESS FEATURES | |
| Coverage | 140m² |
| Concurrent Clients | 250+ |
| Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
| Frequency | 2.4GHz and 5.0GHz |
| Signal Rate | 5.0GHz: up to 4,804Mbps |
| 2.4GHz: up to 574Mbps | |
| Wireless Functions | 1024-QAM |
| 4× Longer OFDM Symbol | |
| OFDMA | |
| Multiple SSIDs (up to 16× SSIDs, 8× for Each Band) | |
| Enable / Disable Wireless Radio | |
| Automatic Channel Assignment | |
| Transmit Power Control (Adjust Transmit Power on dBm) | |
| QoS (WMM) | |
| MU-MIMO | |
| HE160 (160MHz Bandwidth) | |
| Seamless Roaming | |
| Omada Mesh | |
| Band Steering | |
| Load Balance | |
| Airtime Fairness | |
| Beamforming | |
| Rate Limit | |
| Reboot Schedule | |
| Wireless Schedule | |
| Wireless Statistics Based on SSID / AP / Client | |
| Wireless Security | Captive Portal Authentication |
| Access Control | |
| Wireless Mac Address Filtering | |
| Wireless Isolation Between Clients | |
| SSID to VLAN Mapping | |
| Rogue AP Detection | |
| 802.1x Support | |
| WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise | |
| Transmission Power | CE: |
| <20dBm (2.4GHz, EIRP) | |
| <23dBm (5.0GHz, Band1 and Band2, EIRP) | |
| <30dBm (5.0GHz, Band3, EIRP) | |
| FCC: | |
| <25dBm (2.4GHz) | |
| <28dBm (5.0GHz) | |
