- Built-in 9dBi 2×2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 25dBm/500mw
- System-level optimizations for more than 5km long-range wireless transmission
- TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
- Centralized Management System – Pharos Control
- AP / Client / AP Router / AP Client Router (WISP) operation modes
- Passive PoE Adapter supports up to 60 meters (200 feet) Power over Ethernet deployment and allows the device to be reset remotely
HARDWARE FEATURES
Processor: Qualcomm Atheros 560MHz CPU, MIPS 74Kc
Memory: 64MB DDR2 RAM, 8MB Flash
Interface:
– 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)
– 1 Grounding Terminal
– 1 Reset Button
Power Supply:
– Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
– Voltage range: 16-27VDC
Power Consumption: 5 Watts Max
Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
Dimensions ( W x D x H ): 224 x 79 x 60 mm
Antenna Type:
– Built-in 9dBi 2×2 Dual-polarized Directional Antenna
– Beam Width: 65° (H-Plane) / 40° (E-Plane)
– Note: For more details, please refer to datasheet
Protection:
– 15KV ESD Protection
– 6KV Lightning Protection
Enclosure:
– Outdoor ASA stabilized plastic material
– IPX5 waterproof Certification
