The Archer C7 operates both the 2.4GHz and 5GHz bands, ensuring amazing wireless performance. Simple tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band – all at the same time.
- Supports 802.11ac standard – 3 times faster than wireless N speeds
- Simultaneous 2.4GHz 450 Mbps and 5GHz 1300 Mbps connections for 1.75Gbps of total available bandwidth
- USB Port – easily shares files & media with networked devices or remotely via FTP server
- Guest Network Access – provides secure Wi-Fi access for guests sharing your home or office network
- Easy setup and management with Tether App
WIRELESS
Standards: Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds: AC1750
5 GHz: 1300 Mbps (802.11ac)
2.4 GHz: 450 Mbps (802.11n)
WiFi Range: 3 Bedroom Houses3× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity: MediumDual-Band
Allocate devices to different bands for optimal performance
Working Modes: Router Mode
Access Point Mode
HARDWARE
Processor: Qualcomm CPU
Ethernet Ports: 1× Gigabit WAN Port
4× Gigabit LAN Ports
USB Support: 1× USB 2.0 Port
Supported Partition Formats:
NTFS, FAT32
Supported Functions:
FTP Server
Media Server
Samba Server
Buttons: Wi-Fi On/Off Button
Power On/Off Button
WPS/Reset Button
Power: 12 V ⎓ 1.5 A
SECURITY
WiFi Encryption: WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
Network Security: SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network: 1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
VPN Server: OpenVPN
PPTP
SOFTWARE
Protocols: IPv4
IPv6
OneMesh™: OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Parental Controls: URL Filtering
Time Controls
WAN Types: Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service: QoS by Device
Cloud Service: OTA Firmware Upgrade
TP-Link ID
DDNS
NAT Forwarding: Port Forwarding
Port Triggering
DMZ
UPnP
IPTV: IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
DHCP: Address Reservation
DHCP Client List
Server
DDNS: TP-Link
NO-IP
DynDNS
Management: Tether App
Webpage
PHYSICAL
Dimensions (W×D×H): 9.6 × 6.4 × 1.3 in
(243 × 160.6 × 32.5 mm)
Package Contents: Wi-Fi Router Archer C7
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
