- 8× 10/100 Mbps RJ45 ports
- 4× PoE ports transfer data and power on individual cables
- Works with IEEE 802.3af compliant PDs
- Up to 250m data and power transmitting range under Extend Mode**
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
- Supports PoE Power up to 41 W for all PoE ports*
- Plug and play with no configuration required
HARDWARE FEATURES
Interface:
– 8× 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE)
– AUTO Negotiation
– AUTO MDI/MDIX
Network Media:
– 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
– 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
– EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: Yes
External Power Supply: External Power Adapter (Output: 53.5 V DC / 0.81 A)
Packet Forwarding Rate: 1.1904 Mpps
PoE Ports (RJ45):
– Standard: 802.3 af compliant
– PoE Ports: Ports 1–4
– Power Supply: 41 W
Mac Address Table: 2K
Jumbo Frame: 2 KB
Switching Capacity: 1.6 Gbps
Dimensions ( W x D x H ): 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Max Power Consumption:
– 2.2 W (220 V/ 50 Hz. no PD connected)
– 47.1 W (220 V/ 50 Hz. with 41 W PD connected)
Max Heat Dissipation:
– 7.5 BTU/h(no PD connected)
– 160.61 BTU/h(with 41 W PD connected)
